◎ BT50-ER25 90° Double Head Angle Head (AHL Type-Internal Nut)

◎ Run-out : 0.002 mm

◎ Material : Aerospace Alu. Alloy / Alloy Steel

◎ R.P.M. : Max. 6000 RPM

◎ Torque : Max. 25 Nm

◎ Drilling : Max. 14 mm

◎ Tapping : Max. M10

◎ Gear Ratio : 1 : 1

◎ Standard Accessory : Open End Wrench, ER I.N. Wrench

◎ Output Rotation : Same as / Reverse to Input Rotation


IM_EXTRA_TAB_ADD1

◎ Compact and lighter body design is suitable for drilling, milling, and tapping application.

◎ Can be automatic tool changed. Increases productivity.

◎ Enclosed Positioning Pin: Cutting Direction can be adjusted from 0~360 degrees. It allows higher clamping torque and cutting direction could remain during the machining.
